Name: Anti Interference Handheld Battery Tester Lipo Resistance Tester 081KG
Brand: SAIMR
Price: 1000 USD

Brand Name : SAIMR

Model Number : SMR364

Place of Origin : CHINA

MOQ : 1 set

Price : 1000-3000$ per set

Payment Terms : T/T

Supply Ability : 200set/year

Delivery Time : 30 work days

NAME : SMR364 series Handheld Battery Tester

Display : LCD

Features : Portable, easy to use, accurate measurement

resistance resolution : 0.001mΩ

Weight : 0.81KG

Contact Now

SMR364 series Handheld Battery Tester

1.SPECIFICATION

Special for online measurement for UPS batteries
High stability, high resolution design, the highest voltage resolution 0.1mV, and internal
resistance resolution 0.001mΩ
Excellent anti-interference performance. When the instrument receives back EMF shock,
it will automatically cut off the test loop.
SMR364 Use the latest anti-jamming technology to effectively suppress 1/f noise
SMR364A/B/D is a precision tester for ordinary batteries.
Handheld design, lighter and smaller, but their accuracy and speed comparable to the benchtop tester.
Ultra-wide test range, voltage test range up to 1000V (SMR354D only)
Test speed faster than SMR364
It has a minimum resolution of 0.0001mΩ, maximum voltage and auto trigger voltage of 1000V and fastest test speed is 100mS.

2.Application

1.Inspection of high-voltage battery pack and battery module
2.High-speed mass production inspection of various batteries
3.For large, medium and small (low impedance) component inspection and high volume
production inspection
4.Special fuel cell stack inspection
5.Research and development measurement for batteries
6.Simultaneously check internal resistance (IR) and battery voltage (OCV) at high speed

3.SPECIFICATION SELECTION TABLE

Model	Resistance accuracy	Resistance range	Voltage accuracy	Voltage range	Performance characteristics
SMR364	±1%	0.001mΩ~3.100Ω	±0.05%	100μV~60V	Special for online measurement for UPS batteries
SMR364A	±0.5%	0.0001mQ~30.000Q	±0.02%	10μV~100V	Handheld design,lighter and smaller, but their accuracy and speed comparable to the benchtop tester
SMR364B				10μV~300V
SMR364D				10μV~1000V
